Multi-GPU Communication: NVLink, PCIe, and NCCL

How GPUs talk: the bandwidth cliff from HBM to Ethernet, NVLink 5 and GB200 NVL72 topologies, ring AllReduce step by step, and choosing between NCCL, Gloo, and MPI.

Moving data between GPUs adds a communication cost. For a one-way 1 GB transfer, ideal bandwidth-only lower bounds are about 1.11 ms over NVLink 5 (900 GB/s per direction), 15.6 ms over PCIe Gen5 ×16 (64 GB/s), and 80 ms over 100GbE (12.5 GB/s): a 72× spread. These are transfer bounds, excluding latency, protocol overhead, and contention. A collective also depends on rank count and algorithm: a four-rank ring AllReduce sends 1.5 GB per rank for a 1 GB buffer, giving a 1.67 ms bandwidth-only bound at 900 GB/s.

This page is about that wiring: the physical links, the shapes they're arranged in, the collective operations that run over them, and the libraries that pick the algorithms.

The Bandwidth Cliff

Every byte a GPU exchanges lives somewhere on a steep slope. On-package HBM moves terabytes per second; every step away from the die — to a sibling GPU, out of the chassis, across the network — costs roughly an order of magnitude:

The Bandwidth Cliff

Blackwell era (B200, 2024–26)

HBM3E (on package)8 TB/s
↓ NVLink 5 (per GPU)900 GB/s
↓ PCIe Gen6 ×16128 GB/s
↓ InfiniBand XDR (per NIC)100 GB/s
↓ 100G Ethernet12.5 GB/s

Bars are log-scale — each visual step down hides a roughly 10× drop. From the GPU’s own HBM to commodity Ethernet is ~640× less bandwidth. Every communication strategy in distributed training exists to avoid falling further down this cliff than necessary.

Fabric rates use one direction: NVLink aggregates one GPU’s links, PCIe is one ×16 slot, and InfiniBand is one NIC port. HBM is local memory bandwidth across all channels, rather than a network link. Quoted rates are theoretical capabilities, not measured transfer results.

The cliff explains nearly every design decision in distributed training. Tensor parallelism stays inside an NVLink domain because it communicates constantly; data parallelism tolerates crossing nodes because it synchronizes once per step; hierarchical AllReduce exists so traffic falls down the cliff exactly once instead of N times. Data vs tensor vs pipeline parallelism maps each strategy to the link it needs. If you remember one picture from this page, make it this one. (For the top of the cliff, see the HBM page.)

Interconnect Technologies

PCIe: the universal floor

Every GPU speaks PCIe — it's how the CPU loads data, and on systems without NVLink it's also how GPUs reach each other.

GenerationBandwidth (×16, each direction)Mainstream since
PCIe Gen316 GB/s2012
PCIe Gen432 GB/s2019
PCIe Gen564 GB/s2023
PCIe Gen6128 GB/s2026 (servers)

Universal, vendor-neutral — and shared. GPU-to-GPU traffic over PCIe contends with storage and network devices on the same fabric, which is why even Gen6 is the cliff's middle ledge, not its top.

NVLink is NVIDIA's point-to-point GPU link. The table lists both the per-link rate and the number that actually matters — the per-GPU aggregate with all links in use:

GenerationGPULinks × per-linkPer-GPU aggregate
NVLink 1.0P100 (2016)4 × 20 GB/s80 GB/s
NVLink 2.0V100 (2017)6 × 25 GB/s150 GB/s
NVLink 3.0A100 (2020)12 × 25 GB/s300 GB/s
NVLink 4.0H100 (2022)18 × 25 GB/s450 GB/s
NVLink 5.0B200 (2024–26)18 × 50 GB/s900 GB/s

All table rates are per direction. Commonly quoted duplex totals are twice these values: H100 900 GB/s and B200 1.8 TB/s. Latency sits around a microsecond, and transfers bypass the CPU entirely. The catch: NVLink is NVIDIA-only, and since Ada (RTX 40-series) it's gone from consumer cards entirely — multi-GPU on gaming hardware means PCIe, full stop.

NVSwitch: from node to rack

Point-to-point links don't scale to "everyone talks to everyone." NVSwitch is dedicated switch silicon that provides a nonblocking fabric. Each GPU can use its full aggregate injection bandwidth across its peers; concurrent transfers to multiple peers share that per-GPU budget.

  • HGX H100 node: 8 GPUs through 4 NVSwitch chips — 450 GB/s per direction per GPU (900 GB/s duplex).
  • GB200 NVL72 rack: the 2026 flagship dissolves the node boundary — 72 Blackwell GPUs across 18 compute trays wired through 9 NVLink-switch trays into one NVLink domain with 130 TB/s of aggregate duplex bandwidth. Each NVLink 5 Switch chip carries 144 ports at 14.4 TB/s duplex. The "node" is now the rack.

InfiniBand, RoCE, and EFA: crossing machines

Past the rack, traffic rides the network:

TechnologyPer-port rateIn GB/sNotes
InfiniBand HDR200 Gb/s25Common in A100-era clusters
InfiniBand NDR400 Gb/s50H100-era standard
InfiniBand XDR800 Gb/s100Quantum-X800, Blackwell-era
RoCE v2100–800 Gb/svariesRDMA over (lossless) Ethernet
AWS EFA (v3)up to 3,200 Gb/s400Aggregate per P5en instance

GPUDirect RDMA lets the NIC read and write GPU memory directly — no CPU bounce buffer — and modern training nodes pair one NIC per GPU to widen the pipe. Switch-side, Quantum-X800 adds SHARP in-network reduction: the switch itself sums tensors mid-flight, and NCCL 2.27 uses it on both InfiniBand and NVLink fabrics.

GPU Topologies

How your GPUs are wired sets your scaling ceiling before you write a line of code. Explore the four shapes that matter — click any device or link:

Topology Explorer

The standard training node: every GPU reaches every other at full NVLink speed through NVSwitch.

8-GPU HGX node. Select a device or link for details.

Select any device or link to see its bandwidth and where it bottlenecks.

Schematic, not to scale; the NVL72 view groups GPUs by tray rather than drawing all 72. Link colors: teal NVLink, amber PCIe, orange InfiniBand.

Four regimes, in ascending order of money:

  1. Consumer PCIe box — two cards sharing the PCIe fabric. Fine for experimentation; AllReduce tops out at the slot bandwidth, and there is no NVLink escape hatch on 40/50-series cards.
  2. HGX 8-GPU node — the workhorse. NVSwitch makes topology invisible inside the node: no lucky or unlucky GPU pairs.
  3. GB200 NVL72 rack — 72 GPUs, one NVLink domain. Models that needed multi-node tensor parallelism now fit inside a single fabric running at NVLink speed.
  4. Multi-node cluster — NVLink inside each node or rack, InfiniBand/EFA between them, and a 9× bandwidth gap at the boundary (900 GB/s per direction per GPU in-rack vs 100 GB/s per direction per XDR port) that every framework works around with hierarchy.

Collective Operations

Distributed training speaks a small vocabulary of collectives. Watch each one move actual chunks around a 4-GPU ring:

Collective Operations, Step by Step

Gradient sync in data parallelism — every GPU ends with the same summed result.

GPU 0

a0
b0
c0
d0

GPU 1

a1
b1
c1
d1

GPU 2

a2
b2
c2
d2

GPU 3

a3
b3
c3
d3

Step 1 of 7: Start: every GPU holds its own version of all four chunks (its local gradients).

local partial sum final not held

Four GPUs — AllReduce, AllGather, and ReduceScatter use the ring algorithm; Broadcast uses a doubling tree. NCCL selects between ring, tree, and SHARP-offloaded variants by message size and fabric. a0 = chunk a’s version from GPU 0; * = partial sum; Σ = complete sum.

What each is for, with the PyTorch one-liner:

AllReduce — everyone contributes, everyone gets the sum. The heartbeat of data parallelism; DDP calls it on your gradients after every backward pass.

python
torch.distributed.all_reduce(tensor, op=dist.ReduceOp.SUM)

Broadcast — one rank sends, all receive. Weight initialization at startup.

python
torch.distributed.broadcast(tensor, src=0)

AllGather — everyone shares their shard, everyone ends with all shards. Tensor-parallel activations; ZeRO parameter gathering.

python
torch.distributed.all_gather(tensor_list, tensor)

ReduceScatter — sum like AllReduce, but each rank keeps only its slice. ZeRO gradient sharding; exactly half of a ring AllReduce.

python
torch.distributed.reduce_scatter(output, input_list)

Point-to-point — direct send/recv between two ranks. Pipeline parallelism passing activations stage to stage.

python
torch.distributed.send(tensor, dst=next_rank)
torch.distributed.recv(tensor, src=prev_rank)

The ring algorithm in the stepper moves 2(N−1)/N of the data per GPU regardless of N — which is why ring AllReduce is bandwidth-optimal for large messages, while latency-bound small messages prefer tree algorithms. NCCL picks per message size; you rarely should.

Communication Libraries

LibraryVendorHardwareTopology-awareBest for
NCCLNVIDIACUDA GPUsYesAnything NVIDIA — the default
RCCLAMDROCm GPUsYesMI300-class clusters
oneCCLIntelIntel GPUs/CPUsYesIntel Data Center GPUs
GlooMetaCPU + GPUNoCPU fallback, development
MPIcommunityeverythingvariesHPC sites with MPI infrastructure
MSCCLMicrosoftCUDA GPUsprogrammableCustom algorithms, research

NCCL detects your topology (NVLink, PCIe, InfiniBand), then picks ring, tree, or SHARP-offloaded algorithms per message. As of 2.27 it also runs SHARP reductions on NVLink fabrics and offers symmetric memory across domains up to a full NVL72.

python
torch.distributed.init_process_group(backend='nccl')

RCCL is NCCL's API twin for AMD — PyTorch even selects it through the 'nccl' backend name on ROCm. oneCCL covers Intel (backend='ccl' after importing oneccl_bindings_for_pytorch). Gloo (backend='gloo') works everywhere but optimizes nothing — keep it for CPUs and debugging. MPI integrates with schedulers and existing HPC tooling. MSCCL lets you write custom collectives when the built-in algorithms don't fit your topology.

Choosing Your Setup

  1. Vendor picks the library: NVIDIA → NCCL, AMD → RCCL, Intel → oneCCL, mixed or CPU → Gloo/MPI.
  2. Scale picks the fabric: 2 GPUs → PCIe is survivable; 4–8 → you want an NVSwitch node; dozens → NVL72 or multi-node InfiniBand; hundreds+ → multi-node is mandatory, design for the hierarchy.
  3. Consumer hardware reality check: no NVLink since the 3090 — a dual-4090/5090 box is PCIe-only, and that's a constraint to design around, not a bug to fix.

Performance: Living With the Cliff

Bandwidth vs latency. Large transfers (>1 MB) are bandwidth-bound — interconnect choice dominates. Small transfers (<100 KB) are latency-bound — even PCIe looks fine, and the fix is batching, not faster links. DDP's gradient bucketing (bucket_cap_mb, default 25) exists precisely to turn many small AllReduces into few large ones.

Overlap communication with compute. While layer N's gradients sync, layer N−1's are still being computed. Bigger buckets use bandwidth better; smaller buckets start syncing sooner. It's a tunable, not a constant.

Respect the hierarchy. Reduce within the NVLink domain first, cross the network once with the result. DeepSpeed and Megatron do this automatically; manual setups use separate intra- and inter-node process groups.

PracticeWhyHow
Verify topology detectionMisdetection silently costs 10×NCCL_DEBUG=INFO python train.py
Inspect your actual wiringMarketing slides ≠ your motherboardnvidia-smi topo -m
Profile the overlapFind sync stalls visuallynsys profile --trace=cuda,nvtx python train.py
Tune bucketingBalance bandwidth vs overlapDDP(model, bucket_cap_mb=25)
Pin library versionsMixed NCCL versions hang silentlycontainerized environments (NGC)
Gradient compressionCuts cross-node AllReduce traffic when bandwidth-limitedddp_comm_hooks.powerSGD_hook
PitfallSymptomFix
PCIe bottleneckScaling dies beyond 2 consumer GPUsCheck nvidia-smi topo -m; rent NVSwitch nodes
No GPUDirectGradients bounce through CPU memoryConfirm NET/IB (not NET/Socket) in NCCL_DEBUG output
Topology-blind schedulingCluster scatters your 8 GPUs across racksLocality constraints: --gres=gpu:8 --exclusive
Tiny messagesHigh AllReduce latency, idle linksIncrease bucket_cap_mb; fuse small tensors
